| Line Coding: | Trellis On |
| Status: | No Defect |
| Link Power State: | L0 |
|
| Downstream | Upstream |
| SNR Margin (dB): | 11.2 | 11.9 |
| Attenuation (dB): | 26.0 | 14.9 |
| Output Power (dBm): | -2.0 | 6543.6 |
| Attainable Rate (Kbps): | 20344 | 1603 |
| Rate (Kbps): | 4703 | 316 |
| MSGc (number of bytes in overhead channel message): | 59 | 16 |
| B (number of bytes in Mux Data Frame): | 146 | 14 |
| M (number of Mux Data Frames in FEC Data Frame): | 1 | 1 |
| T (Mux Data Frames over sync bytes): | 1 | 2 |
| R (number of check bytes in FEC Data Frame): | 0 | 16 |
| S (ratio of FEC over PMD Data Frame length): | 0.9932 | 1.4675 |
| L (number of bits in PMD Data Frame): | 1184 | 169 |
| D (interleaver depth): | 1 | 1 |
| Delay (msec): | 0 | 0 |
|
| Super Frames: | 225082 | 225080 |
| Super Frame Errors: | 24 | 2117 |
| RS Words: | 0 | 15305440 |
| RS Correctable Errors: | 0 | 33865 |
| RS Uncorrectable Errors: | 0 | N/A |
|
| HEC Errors: | 17 | 25802 |
| OCD Errors: | 0 | 0 |
| LCD Errors: | 0 | 0 |
| Total Cells: | 241652269 | 3176839105 |
| Data Cells: | 4895041 | 92276707 |
| Bit Errors: | 0 | 2053739 |
|
| Total ES: | 351 | 546 |
| Total SES: | 33 | 280 |
| Total UAS: | 61 | 4381234 |
